325 mesh twill weave stainless steel wire mesh

325 mesh twill weave stainless steel wire mesh

Standard

GB/T 5330.1-2000,  GB/T 19628.2-2005

Anping Web Wire Mesh Co.,LTD Twill Weave Process and Technical Parameter

Brief description of 325 mesh twill weave stainless steel wire mesh

325 mesh twill weave stainless steel wire mesh including 325 wires and openings of 1 inch Using 0.035-0.04mm diameter wire, by twill weaving, woven 325 mesh opening for 0.038-0.043mm liquid or gas filter . This wire diameter and mesh with ratio reasonable, therefore weave structure is very strong. After 13 whole weaving process, so that the mesh surface flatness better

Material

300 series: 304L 316 316L

Common Grade	Characteristics
304L	A low-carbon version of 304. The lower carbon content makes the wire softer for easier weaving and significantly improves its welding characteristics.
316	Offers superior resistance to pitting corrosion from chlorides, brines, and halogens compared to 304. It features high creep strength at high temperatures and excellent durability at sub-zero temperatures. Widely used for chemical processing mesh.
316L	A low-carbon version of 316. It provides better wire flexibility for weaving and eliminates the risk of intergranular corrosion after welding.

325 mesh twill weave stainless steel wire mesh technical parameter

roll width: 1.0-1.6m

roll length: 30m

325 mesh twill weave stainless steel wire mesh application

Capillary wicking for rebuildable atomizers : mesh wicking material, vaping mesh sheets, rebuildable atomizer mesh wicks, electronic cigarette atomizer mesh inserts

Laboratories and filters: test sieves, screening and filtering , laboratory screening media, particle sizing screens,shale shaker screen

Chemical and hydraulic oil filters: oil filter, hydraulic filters, fiber spinning mesh, screening and filtering ,hydraulic oil strainer, synthetic fiber spin-pack micro-filtration discs, polymer melt conditioning wire mesh, engine oil filter packs,micro-particulate hydraulic filter gaskets,oil line strainers

Pharmaceutical drug preparation:pharmaceutical powder preparation,pharmaceutical ingredient sifters

325 mesh twill weave stainless steel wire mesh packing

Stainless steel wire mesh is packed in rolls,winding on a paper tube,wrapped in moisture-proof paper

or plastic film, outside wooden cases or wooden pallet.
